Description
Product details
Display method4-digit 7-segment LEDControl methodON/OFF control, P, PI, PD, PID controlInput specificationThermocouple: K(CA), J(IC), T(CC), R(PR), S(PR), L(IC) RTD: DPt100?, Cu50℃Sampling cycle100msControl outputRelay(250VAC~ 3A) or SSR drive(12VDC ) [ON/OFF]Option outputAlarm 1/2Power supply100-240VAC~ 50/60HzApprovalDisplay accuracy_RTD•At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit •Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digitDisplay accuracy_Thermocouple•At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit •Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digitHysteresis(adjustable sensitivity)1 to 100℃/℉(0.1 to 50.0℃/℉) variableProportional band0.1 to 999.9?/?Integral time0 to 9999 secDerivative time0 to 9999 secControl period0.5 to 120.0 secManual reset0.0 to 100.0%Environment_Ambient temperature-10 to 50?, storage: -20 to 60℃Environment_Ambient humidity35 to 85% RH, storage: 35 to 85% RHInsulation typeDouble insulation or reinforced insulation(mark: , dielectric strength between the measuring input part and the power part: AC power 2
