SPECIFICATIONS Nominal Motor HP [kW]1 Hp [0.75 kW] (ND & HD & HND) 0.5 Hp [0.4 kW] (HHD - Constant Torque)Rated Output Capacity kVA1.6 kVA (ND) 1.4 kVA (HD & HND) 1.1 kVA (HHD)Rated Output Voltage3 Phase, 380-480 Volt (with AVR)Rated Output Current2.1 Amps (HD) 1.8 Amps (HD & HND) 1.5 Amps (HHD)Rated Overload Capability120 % of nominal current for 1 minute (ND & HND) 150 % of nominal current for 1 minute (HD) 150 % of nominal current for 1 minute or 200% of nominal current for 0.5 seconds (HHD)Main Power Supply Input3 Phase, 380 to 480 Volt, 50/60 Hz (With AVR)Voltage / Frequency VariationsVoltage: +10 % to -15% Voltage Unbalance: 2% or less Frequency: +5% to -5%Rated Current Input without DC Reactor [with DC Reactor]2.7 Amps [1.5 Amps] (ND & HD & HND) 1.7 Amps [0.85 Amps] (HHD)Required Power Supply Capacity1.1 kVA (ND & HD & HND) 0.6 kVA(HHD)Braking Torque53 % (ND & HD & HND) 100 % (HHD)DC BrakingStarting frequency: 0.0 to 60.0 Hz Braking Time: 0.0 to 30.0 Seconds Braking Level: 0 to 60 % (ND),0 to 80 % (HD & HND), 0-100 % (HHD) of nominal currentBraking ChopperBuilt-InBraking ResisterOptionalMinimum Connectable Resistance200 ?DC ReactorOptional, DCR4-0.75 (ND & HD & HND) Optional, DCR4-0.4 (HHD)CoolingNatural CoolingOptional Din Rail MountRMA-E2-2.2EMC FilterOptionalDimensions4.33" x 5.51" x 4.69"Weight2.6
